Fronius 4,240,038,Z Datamanager 2.0 WLAN

Fronius 4,240,038,Z Datamanager 2.0 WLAN for Galvo / Primo / Symo

The Fronius Datamanager is the communications center for Fronius inverters in every type of application. Whenever it is connected to the internet via a LAN or Wi-Fi, the Fronius Datamanager sends the PV system data directly to the Fronius Solar.web online portal. This provides you with an overview of how the system is operating at all times. The integrated Modbus RTU SunSpec, Modbus TCP SunSpec and Fronius Solar API (JSON for actual values) interfaces allow Fronius inverters to be seamlessly linked to third-party systems and run in parallel with Fronius Solar.web.

The Fronius Datamanager 2.0 is integrated into the Fronius Galvo and Fronius Primo inverters as standard. Fronius Datamanager can be retrofitted to existing inverters. Different form factors of the Fronius Datamanager 2.0 are available for the Fronius CL/IG/ IG Plus and the Fronius SnapINverter lines: article number 4,240,034 for Fronius CL/IG/IG Plus and article number 4,240,038 for Fronius Galvo/Primo/Symo.

Data

• Storage capacity: max. 4096 days
• Supply voltage: 12 V DC – power supplied by inverter
• Energy consumption: < 2,0 W
• Height: 5,2 in
• Width: 4,06 in
• Length: 0,87 in
• Operating temperature range: -20°C - +65°C

Interfaces

• Ethernet (RJ45 socket): LAN, 10/100 MBit / Fronius Solar.web, Modbus TCP SunSpec, Fronius Solar API (JSON)
• RS422 (RJ45 socket): Fronius Solar.Net IN
• WLAN: Wireless standard 802.11 b/g/n / Fronius Solar.web, Modbus TCP SunSpec, Fronius Solar API (JSON)
• 6 digital inputs: Interface to ripple control receiver
• 4 digital inputs/outputs: Interface to ripple control receiver, load management
• RS485: Modbus RTU SunSpec or meter connection

Attachments

• Fronius Datamanager 2.0 Datasheet
• Fronius Datamanager Operating Instructions
