Description
Fronius 4,210,141,800 Primo GEN24 5.0 Grid-Tie Single-Phase String Inverter 208-240
The Fronius GEN24 maximizes energy production and performance. Innovative software, high efficiency, and advanced functionality make this inverter optimal for homeowners looking to start or enhance their energy independence. Even in shaded areas, the Fronius GEN24 delivers maximum yields.
More assurance when you need it: Equipped with PV Point, the Fronius GEN24 offers a integrated backup power function that supplies connected devices with reliable solar power when the sun is shining.
Features
- Built-in longevity: The Active Cooling Technology keeps the power electronics of Fronius inverters at a low temperature, thus ensuring a long service life.
- Flexibility for greater potential: The SuperFlex Design ensures easy configuration even on complex roofs.
- Multi-award winning inverter manufactured in Europe
Integrated shade management
Highest yields even in shade: That's what the Fronius GEN24 achieves with the Dynamic Peak Manager. The intelligent algorithm optimizes PV yields at the string level, eliminating the need for expensive additional module level optimization components.
Backup power for your needs
Energy supply needs security. The Fronius GEN24 therefore offers an integrated basic backup power supply. Connected devices up to 3 kW are supplied with backup power via the PV Point - a protected outlet - as long as the sun is shining.
Support throughout
From initial planning through commissioning to future maintenance: our digital solutions and services provide comprehensive support for the Fronius GEN24. And to make your life as an installer even easier, quick-release screws and push-in spring terminals speed up the installation process.
Solar.start – the app by pros for pros
Configure Fronius inverters in just a few minutes: Solar.start makes it easy for you. Quick and easy commissioning in just three steps:
- 1. Network settings
- 2. Product configuration
- 3. Integration into the Fronius Solar.web monitoring platform
- Quick access to the web interface for additional settings and functions
- Full warranty coverage when you register the inverter on Solar.web
- Link to useful platforms such as Solar.web and Solar.SOS
FAQs
- If I place different size strings on one MPPT tracker, will it work?
Yes, it will work. However, you will be losing production because the inverter will lower both strings to the string with the lowest voltage. The solution is to make certain that each string is the same size on one MPPT tracker. The strings can be different sizes if the strings are on different MPPT trackers. - If I place a string facing one direction and another string facing another direction on the same tracker, will it work?
Yes, it will work. However, you will be losing production because one string may be generating a certain voltage facing one direction and the other string may be generating a different voltage facing in another direction. The inverter will lower both strings to the string with the lowest voltage. The solution is to make certain that each string on one MPPT tracker is facing one direction. The strings can be facing different directions as long as they are on separate MPPT trackers.
Attachments
