S-5! S-5-N Standing Seam Metal Roof Clamp
The S-5-N (“N” stands for nail strip) is a non-penetrating, standing seam metal roof (SSMR) clamp. The N fits popular 1″ nail strips, such as: Taylor Metals’ Easy Lock™, ASC Building Products’ Skyline Roofing®, New Tech Machinery’s FF100 and roofing types with similar profiles. For nail strip profiles with 1.5” seam height, see “S-5-NH 1.5.”
Minis Available
The N Mini clamp is a more economical solution for lighter-duty attachments where Herculean holding strength is not required. All standard and Mini clamps undergo rigorous load testing. Negative load normal-to-seam testing (pull-up) is performed on all Mini clamps, and parallel-to-seam testing (drag load) is performed on all standard clamps.
Choose the N to mount to nail flange metal roof profiles with a base of rib dimension ≤ .82” (20 mm).
What's included?
- (1) S-5-N
- (1) S-5-N insert
- (1) M8 Bolt
- (2) T-30 Torx round-point setscrews
